Conventional fire alarm systems smoke detector sensor with self-check function

• Feature:
• self-check button:could self-check circuit and all components works normally or not.(also alarm if labyrinth not install well)
• exact smoke concentration & alarm consistency:All detector will calibrating consistency,make sure no fake alarm with less or too much smoke.
• could load the strong electricity:have contact output function. The 4 wires could alarm and connect 220V or 9-35V sounder alarm etc
• small alarm current:Our smoke detector could connect 50pcs each zone on the converntional fire alarm control panel

Specifications:

Operating voltage: DC 9-35V

• Standby current: less than 2mA
• Alarm current: less than 10mA
• Operating temperature: -10℃to +50℃
• Working humidity: less than 95%RH
• Alarm mode: network output / LED indicator
• Detecting area:80 square meters (with the installation
• height of 6m-12m), and 60 square meters (with the installation height of less than 6m)
• Sensitivity: class I
• Alarm output: relay output
• Dimension: 100(diaMETER) * 42mm(deep)
